A new species of Luganoia (Luganoiidae, Neopterygii) from the Middle Triassic Xingyi Biota, Guizhou, China

doi:10.19615/j.cnki.1000-3118.200624

Abstract

Abstract:

Neopterygii is the largest known group of ray-finned fishes today, and the Luganoiidae, recognized by its specialized skull and greatly deepened flank scales, is a stem lineage of this group in the Middle Triassic. Since its naming in 1939, the Luganoiidae has been represented solely by the marine species Luganoia lepidosteoides found near the Ladinian/Anisian boundary of the southern and eastern Switzerland, northern Italy and southeastern Spain. Here, I report the discovery of a new species of this genus, Luganoia fortuna sp. nov. based on a nearly complete specimen from the late Middle Triassic (Ladinian) marine deposits exposed near Xingyi, Guizhou, China. The discovery represents the first record of the Luganoiidae in Asia, indicating that the biogeographical distribution of this family is much wider than previously recognized. Comparative studies of the new species with the type species from Europe reveal some anatomical features previously unnoticed in Luganoia, e.g., the presence of antorbitals, absence of a plate-like quadratojugal, presence of a narrow naked region of the body at the base of the dorsal fin, presence of a small anal fin closer to the caudal fin than to the pelvic fin, and absence of postcleithra. An amended diagnosis of the genus is presented. Moreover, the distinguishable features between the Chinese and European species are highlighted in this study, and they provide valuable information on the morphological diversification of Luganoia.

Key words: Xingyi, Guizhou, Triassic, Luganoiidae, Neopterygii, osteology, paleobiogeography

摘要：

新鳍鱼类是辐鳍鱼亚纲中最大的现生类群,中三叠世卢加诺鱼科则是新鳍鱼类干群中的一支,具有特化的头骨和特别高的侧腹鳞片。自1939年命名以来,卢加诺鱼科仅以瑞士东部和南部、意大利北部和西班牙东南部中三叠世海相地层安尼期/拉丁期界线附近发现的瓷鳞卢加诺鱼(Luganoia lepidosteoides)为唯一代表。根据贵州兴义中三叠世晚期(拉丁期)海相地层发现的一块较完整的精美鱼化石,命名了卢加诺鱼属一新种,祥瑞卢加诺鱼(Luganoia fortuna sp. nov.)。新种代表了卢加诺鱼科在亚洲的首次出现,表明此科的生物地理分布比之前认识的要大很多。基于新种与模式种的比较研究,修订了卢加诺鱼属的鉴定特征,揭示了该属过去一些未注意到的解剖学特征,例如存在一对眶前骨,缺少板片状的方颧骨,背鳍基部具有一狭长的裸露身体区域;臀鳍很小,与尾鳍的距离比与腹鳍更近;后匙骨缺失。此外,详细列举了中国新种与欧洲模式种的形态差异,研究结果为了解卢加诺鱼属的形态多样性提供了重要信息。

关键词: 贵州兴义, 三叠纪, 卢加诺鱼科, 新鳍鱼类, 骨骼学, 古地理

CLC Number:

Q915.862

XU Guang-Hui. A new species of Luganoia (Luganoiidae, Neopterygii) from the Middle Triassic Xingyi Biota, Guizhou, China. Vertebrata Palasiatica, 2020, 58(4): 267-282.

徐光辉. 2020, 58(4): 267-282, 贵州中三叠世兴义生物群卢加诺鱼属(卢加诺鱼科,新鳍鱼类)一新种. 古脊椎动物学报.

Figures/Tables 5

References 48

[1]	Arratia G, 2013. Morphology, taxonomy, and phylogeny of Triassic pholidophorid fishes (Actinopterygii, Teleostei). Soc Vert Paleont Mem (Supp J Vert Paleont), 13:1-138
[2]	Bartram A W H, 1977. The Macrosemiidae, a Mesozoic family of holostean fishes. Bull Br Mus Geol, 29:137-234
[3]	Benton M J, Zhang Q Y, Hu S X et al., 2013. Exceptional vertebrate biotas from the Triassic of China, and the expansion of marine ecosystems after the Permo-Triassic mass extinction. Earth Sci Rev, 125:199-243
[4]	Brough J, 1939. The Triassic fishes of Besano, Lombardy. London: British Museum (Natural History). 1-117
[5]	Bürgin T, 1992. Basal ray-finned fishes (Osteichthyes; Actinopterygii) from the Middle Triassic of Monte San Giorgio (Canton Tessin, Switzerland). Schweiz Paläont Abh, 114:1-164
[6]	Bürgin T, 1999. Middle Triassic marine fish faunas from Switzerland. In: Arratia G, Schultze H-P eds. Mesozoic Fishes 2 - Systematics and Fossil Record. München: Verlag Dr. F. Pfeil. 481-494
[7]	Cartanyà J, 1999. An overview of the Middle Triassic actinopterygians from Alcover, Mont-Ral and El Pinetell (Catalonya, Spain). In: Arratia G, Schultze H-P eds. Mesozoic Fishes 2 - Systematics and Fossil Record. München: Verlag Dr. F. Pfeil. 535-552
[8]	Chen Z, 1985. Stratigraphical position of Keichousaurus hui from the Middle Triassic of southwestern Guizhou and its significance. Guizhou Geol, 5:289-290
[9]	Gardiner B G, Schaeffer B, 1989. Interrelationships of lower actinopterygian fishes. Zool J Linn Soc, 97(2):135-187
[10]	Geng B H, Zhu M, Jin F, 2009. A revision and phylogenetic analysis of Guizhoucoelacanthus (Sarcopterygii, Actinistia) from the Triassic of China. Vert PalAsiat, 47:165-177
[11]	Grande L, Bemis W E, 1998. A comprehensive phylogenetic study of amiid fishes (Amiidae) based on comparative skeletal anatomy: an empirical search for interconnected patterns of natural history. Soc Vert Paleont Mem (Suppl J Vert Paleont), 4: 1-690
[12]	Griffith J, 1977. The Upper Triassic fishes from Polzberg bei Lunz, Austria. Zool J Linn Soc, 60(1):1-93
[13]	Herzog A, Bürgin T, 2005. A new species of the genus Besania Brough 1939 from the Middle Triassic of Canton Grisons (Switzerland) with a discussion of the phylogenetic status of the taxon. Eclogae Geol Helv, 98(1):113-122
[14]	Jin F, 2001. Notes on the discovery of Birgeria in China. Vert PalAsiat, 39:168-176
[15]	Lehman J-P, 1958. Superordre des Chondrostéens. Formes fossils. In: Grassé P P ed. Traité de zoologie, Tome 13, fasc 3. Paris: Masson et Cie. 2130-2164
[16]	Li C, Wu X C, Zhao L J et al., 2016. A new armored archosauriform (Diapsida: Archosauromorpha) from the marine Middle Triassic of China, with implications for the diverse life styles of archosauriforms prior to the diversification of Archosauria. Sci Nat, 103:95
[17]	Li J L, 2006. A brief summary of the Triassic marine reptiles of China. Vert PalAsiat, 44:99-108
[18]	Li J L, Jin F, 2009. Swimming in the Ocean Two Hundred Million Years Ago: Triassic Marine Reptile and Environment of South China. Beijing: Science Press. 1-145
[19]	Li Z G, Sun Z Y, Jiang D Y et al., 2016. LA-ICP-MS Zircon U-Pb age of the fossil layer of Triassic Xingyi Fauna from Xingyi, Guizhou, and its significance. Geol Rev, 62:779-790
[20]	Liu G B, Yin G Z, Wang X H, 2002. On the most primitive amiid fish from Upper Triassic of Xingyi, Guizhou. Acta Palaeont Sin, 41:461-463
[21]	Liu G B, Yin G Z, Wang X H et al., 2003. New discovered fishes from Keichousaurus bearing horizon of Late Triassic in Xingyi of Guizhou. Acta Palaeont Sin, 42:346-366
[22]	Lombardo C, 1999. Sexual dimorphism in a new species of the actinopterygian Peltopleurus from the Triassic of northern Italy. Palaeontology, 42(4):741-760
[23]	Lombardo C, Brambillasca F, 2005. A new perleidiform (Actinopterygii, Osteichthyes) from the Late Triassic of northern Italy. Boll Soc Paleontol Ital, 44:25-34
[24]	Lu H, Jiang D Y, Motani R et al., 2018. Middle Triassic Xingyi Fauna: showing turnover of marine reptiles from coastal to oceanic environments. Palaeoworld, 27(1):107-116
[25]	Mutter R J, Herzog A, 2004. A new genus of Triassic actinopterygian with an evaluation of deepened flank scales in fusiform fossil fishes. J Vert Paleont, 24(4):794-801
[26]	Patterson C, 1973. Interrelationships of holosteans. In: Greenwood P H, Miles R S, Patterson C eds. Interrelationships of Fishes. Zool J Linn Soc, 53(Suppl):233-305
[27]	Regan C T, 1923. The skeleton of Lepidosteus, with remarks on the origin and evolution of the lower neopterygian fishes. Proc Zool Soc London, 1923: 445-461
[28]	Schröder K M, López-Arbarello A, Ebert M, 2012. Macrosemimimus gen. nov. (Actinopterygii, Semionotiformes) from the Late Jurassic of Germany, England and France. J Vert Paleont, 32(3):512-529
[29]	Su D Z, 1959. Triassic fishes from Kueichow, Southwest China. Vert PalAsiat, 3:205-210
[30]	Sun Z Y, Lombardo C, Tintori A et al., 2012. Fuyuanperleidus dengi Geng et al. 2012 (Osteichthyes, Actinopterygii) from the Middle Triassic of Yunnan Province, South China. Riv Ital Paleont Stratigr, 118:359-373
[31]	Sun Z Y, Lombardo C, Tintori A et al., 2015. A new species of Altisolepis (Peltopleuriformes, Actinopterygii) from the Middle Triassic of southern China. J Vert Paleont, 35(2):e909819, doi: 10.1080/02724634.2014.909819
[32]	Tintori A, Sassi D, 1992. Thoracopterus Bronn (Osteichthyes: Actinopterygii): a gliding fish from the Upper Triassic of Europe. J Vert Paleont, 12(3):265-283
[33]	Tintori A, Sun Z Y, Ni P G et al., 2015. Oldest stem Teleostei from the late Ladinian (Middle Triassic) of southern China. Riv Ital Paleont Stratigr, 121:285-296
[34]	Wang C Y, Kang P Q, Wang Z H, 1998. Conodont-based age of the Keichousaurus hui Yang, 1958. Acta Micropalaeont Sin, 15:196-198
[35]	Wen W, Hu S X, Zhang Q Y et al., 2019. A new species of Platysiagum from the Luoping Biota (Anisian, Middle Triassic, Yunnan, South China) reveals the relationship between Platysiagidae and Neopterygii. Geol Mag, 156(4):669-682
[36]	Westoll T S, 1944. The Haplolepidae, a new family of Late Carboniferous bony fishes-A study in taxonomy and evolution. Bull Am Mus Nat Hist, 83:1-121
[37]	Xu G H, 2019. Osteology and phylogeny of Robustichthys luopingensis, the largest holostean fish in the Middle Triassic. PeerJ, 7:e7184 DOI URL PMID
[38]	Xu G H, Ma X Y, 2016. A Middle Triassic stem-neopterygian fish from China sheds new light on the peltopleuriform phylogeny and internal fertilization. Sci Bull, 61:1766-1774
[39]	Xu G H, Ma X Y, 2018. Redescription and phylogenetic reassessment of Asialepidotus shingyiensis (Holostei: Halecomorphi) from the Middle Triassic (Ladinian) of China. Zool J Linn Soc, 184(1):95-114
[40]	Xu G H, Wu F X, 2012. A deep-bodied ginglymodian fish from the Middle Triassic of eastern Yunnan Province, China, and the phylogeny of lower neopterygians. Chinese Sci Bull, 57(1):111-118
[41]	Xu G H, Zhao L J, 2015. From Potanichthys to Wushaichthys: resolving the evolutionary origin and reproductive strategy of the Thoracopteridae. Biol Lett, 11:20150604 URL PMID
[42]	Xu G H, Zhao L J, Gao K Q et al., 2012. A new stem-neopterygian fish from the Middle Triassic of China shows the earliest over-water gliding strategy of the vertebrates. Proc R Soc B, 280:20122261 DOI URL PMID
[43]	Xu G H, Gao K Q, Coates M I, 2015a. Taxonomic revision of Plesiofuro mingshuica from the Lower Triassic of northern Gansu, China, and the relationships of early neopterygian clades. J Vert Paleont, 35(6):e1001515, doi: 10.1080/02724634.2014.1001515
[44]	Xu G H, Zhao L J, Shen C C, 2015b. A Middle Triassic thoracopterid from China highlights the evolutionary origin of overwater gliding in early ray-finned fishes. Biol Lett, 11:20140960 URL PMID
[45]	Xu G H, Ma X Y, Ren Y, 2018a. Fuyuanichthys wangi gen. et sp. nov. from the Middle Triassic (Ladinian) of China highlights the early diversification of ginglymodian fishes. PeerJ, 6:e6054, doi: 10.7717/peerj.6054 DOI URL PMID
[46]	Xu G H, Ma X Y, Zhao L J, 2018b. A large peltopleurid fish from the Middle Triassic (Ladinian) of Yunnan and Guizhou, China. Vert PalAsiat, 56:106-120
[47]	Young C C, 1958. On the new pachypleurosauroidea from Keichow, Southwest China. Vert PalAsiat, 2:69-81
[48]	Zou X D, Balini M, Jiang D Y et al., 2015. Ammonoids from the Zhuganpo Member of the Falang Formation at Nimaigu and their relevance for dating the Xingyi Fossil-Lagerstaette (late Ladinian, Guizhou, China). Riv Ital Paleont Stratigr, 121:135-161
